Jupiter 20RL

  • Brand:EPELSA
  • Model:20 RL

Retail counter scale with label printer,automatic repositioning to Zero,Zero key,Possibility to print under minimum load according to the calibration standards.Interconnection of up to 10 equipments via Ethernet,all models in the range compatible on the same network.Connection via XDSL.RS232 communications port.
Communication with PC and software update via RS232 and Ethernet.


Backlit alphanumeric display with high contrast on both sides of buyer and seller with a 7 segment line for Weight,Price and Amount and 16 digits and 14 segments alphanumeric line for product description and menu options.

98-key keyboard with 49 direct PLUs and 49 function keys. Possibility of 10 DIRECT TABLES programming for a quick access to PLUs,10 active salesclerks.Stand-by key that disconnects the equipment but leaves the communication server active.Direct keys for printing, total delete, programming and PLU listings.

ARM 4 MB RAM memory microprocessor,data base
(standard version):
 Number of tickets: 10.000
Ticket lines: 20.000
Bitmap size: 12 KB (2 possible Bitmaps )
Countries: 50
 Price changes: 200
 Encoded tares: 10
Goods: 30
VAT: 5
Bovine: 255
Text: 34
Bar codes: 14
Salesclerk keys: 10
Salesclerks: 100
Orders: 100
Formats: 80
Packaging: 8.300
Descriptive: 32.767
Article: 10.000 (expandable)
Clients: 500
Operating Temperature:-10º a +40ºC
Voltage:Between 100v and 240V.
Current Consumption:Between 40 to 60w
Frequency:50 / 60 HZ
